Polaris 600 RUSH 2010 User Manual

1.3
General Information
1
NOTE: * = Rider weight in everyday clothing.
** = From full soft (CCW) position.
General
Width (in/cm) 48 / 121.9
Length (in/cm) 108 / 274
Height (in/cm) 46 / 117
Estimated Dry Weight (lb/kg) 459 / 208
Fuel (Gallons / Liters) 11 / 41.6
Oil (Quarts / Liters) 3.4 / 3.3
Cooling System Capacity(Qts/ L) 5.25 / 5.0
Brake Fluid DOT 4
Drive Belt
Part Number
Width (inches / cm)
Side Angle
Circumference (inches / cm)
Center Distance (inches / cm)
3211122
1.460
/ 3.7
26°
46.77 / 118.8
11.5 / 29.2
Chaincase
Center Distance (inches)
Top Gear (Stock)
Bottom Gear (Stock)
Chain (Stock)
Gear Lube
Capacity (oz / ml)
Reverse System
7.53
23
39
72
Po
laris Synthetic (80W)
9 / 266
PERC
Electrical
Alternator Output
Operating Voltage
Watts @ 13.5 VDC (Total)
13.5 - 14.5 VDC
400
Ignition Timing
18
° @1700 RPM
Coolant Temp = 120
° F (49° C)
Spark Plug Gap in.(mm) .027 (.70)
Spark Plug NGK BPR9ES
Front Suspension
Suspension Type PRO-RIDE
Shocks
Walker Evans Needle w/Remote
Reservoir
16 Click Compression Adjust
able
Factory Setting** = 6
IFS Spring Rate
lbs/in (N/mm)
80 (14)
IFS Spring Installed
Length - Inches (cm)
Preload = 3.75 (9.5)
10.25 (26)
Front Vertical Travel
Inches (cm)
9 (22.9)
Ski Center Distance
Inches (cm)
Setup Width
42.5 (108)
41
.52 (105)
Camber Inches (cm) 1.68  0.31 (4.3  .8
)
Toe Out Inches (mm) 0 -1/8 (0
- 3)
Rear Suspension
Suspension Type Pro-Ride Progressive
Front Track Shock
(FTS)
Walker Evans w/Remote Reservoir
16 Click Com
pression Adjustable
Factory Setting** = 2
FTS Spring Rate
lbs/in (N/mm)
120 - 310 (21 - 54.25)
FTS Spring Installed
L
ength
Inches (cm)
Preload = .75 (1.9)
7.7
5 (19.7)
Rear Track Shock
(RTS)
Walker Evans Needle
w/Remote Reservoir
16 Click Compression Adjustable
Factory Setting** = 4
Standard RTS Spring
Rider Weight*
120 - 250lbs.
Rate lbs/in (N/mm)
PN: 7043572-385
1
90 (33.25)
LW RTS Spring
Rider Weight*
90 - 150lbs.
Rate lbs/in (N/mm)
PN: 7041575-385
120
(21)
HD RTS Spring
Rider Weight*
240 - 335+lbs.
Rate lbs/in. (N/mm)
PN: 7043585-385
2
60 (45.5)
RTS Spring
Rider / Weight Setting
Spring length set to rider weight
using
adjustment gauge.
STD Gauge PN: 5253792
LW Gauge PN: 5253854
HD Gauge PN: 5253855
(STD gauge in tool kit. LW and HD
gauges are accessories and should
be ordered when ordering a LW or
HD spring.)
Rider weight adjustment can also be
performed using tape measure and
RTS Spring Guide Table located in
the Steering/Suspension Chapter.
Rear Travel
Inches (cm)
14 (35.6)

Polaris 600 RUSH 2010 Specifications

General

Horsepower	120 HP
Engine Displacement	599 cc
Cylinders	2
Cooling	Liquid
Bore x Stroke	77.25 mm x 64 mm
Fuel System	Cleanfire Injection
Ignition	Digital CDI
Front Suspension	PRO-RIDE
Rear Suspension	PRO-RIDE
Track Width	15 in
Track Lug Height	1.25 in
Front Travel	9 in
Ski Stance	42.5 in
Brake	Hydraulic Disc
Width	48 in
Starter	Electric
Drive Clutch	P-85
Track Length	121 in
Rear Travel	14 in
Ski Type	Gripper
Driven Clutch	TEAM
