34.Connect the ECU to the wiring harness
3#
.
35.Carefully install the intake tube as an assembly.
NOTICE
Ensure the intake tube is properly seated to the air box
and properly aligned with the intake plenum.
36.Install the diagnostic connector
3$
from the cap.
37.Install the fastener
3%
retaining the lower intake tube.
38.Install the ziptie
3^
securing the upper intake tube to
the chassis.
39.Install the push rivets
3&
retaining the intake tube to
the intake plenum.
40.Turn the handlebar to the right.
41.Install the torx fasteners
3*
and push rivets
3(
retaining the intake plenum.
42.Connect the oil tank
4)
and oil line
4!
.
43.Slide the rear of the oil tank into the profile at the rear
of the clutch cover.
