9850060 R02 - 2020-2021 850 AXYS™ Long Track Snowmobile Service Manual
© Copyright Polaris Inc.
6.41
3. Route the brake line on the front side of the handle bars, behind the electrical harness as shown.
IMPORTANT
The brake line should not be secured with a panduit strap at the handlebars with the wiring harness. The brake line is
designed to float from the banjo bolt to the retention points.
4. Finish routing by routing the brake line up to the brake master cylinder and secure with banjo bolt
e
.
FINAL DRIVE / BRAKE SYSTEMS
