9850060 R02 - 2020-2021 850 AXYS™ Long Track Snowmobile Service Manual
© Copyright Polaris Inc.
20.Install the rebound valve stack onto the shock rod.
Install a new lock nut and torque to specification.
TORQUE
Shock Rod Lock Nut:
20 ft-lbs (27 Nm)
21.Remount the shock body assembly in the vise. Set
the clicker to full soft. Fill the shock body with new
shock oil until the reservoir is completely full.
22.Install a new wear band
q
and O-ring
w
onto the IFP.
Verify the bleed screw and O-ring are removed from
the IFP. Coat the IFP with shock oil.
23.Slowly Insert the IFP into the reservoir using the T-
handle tool. Allow as much air as possible to escape
as the IFP is installed.
24.Slowly stroke the IFP up and down to bleed air from
the shock. be sure to bottom-out the IFP in the
reservoir. Allow sufficient time for all air bubbles to
dissipate. Repeat this process until all air is removed.
25.After the air has been bled, set the IFP so it is
approximately 1.5" (3.8 cm) from the top of the
reservoir. Remove the T-handle tool and install the O-
ring and bleed screw.
STEERING / SUSPENSIONS
