SCHEMATIC CABLE/WIRE TERMINATION TABLE
INDEX CCT # TYPE GAUGE COLOR FROM COMPONENT FROM PORT TO COMPONENT TO PORT FUNCTION
1 01 TXL 0.5 VT/WH CHASSIS/HOOD 10 FUEL PUMP 2 FUEL LEVEL
2 03 TXL 0.5 WH/BK CHASSIS/HOOD 4 CONSOLE JUMPER E SET SWITCH
3 04 TXL 0.5 WH/RD CHASSIS/HOOD 12 CONSOLE JUMPER C MODE SW
4 06 TXL 0.5 WH CHASSIS/HOOD 6 ELECTRIC START 4 STARTER SOLENOID CONTROL
5 BUSA_3_5 BUS BUS BUS LOAD CENTER A3 LOAD CENTER A5 CHASSIS LOAD CENTER BUS
6 BUSA_5_7 BUS BUS BUS LOAD CENTER A5 LOAD CENTER A7 CHASSIS LOAD CENTER BUS
7 BUSB_5_7 BUS BUS BUS LOAD CENTER B5 LOAD CENTER B7 EV LEARN LOAD CENTER BUS
8 BUSB_7_9 BUS BUS BUS LOAD CENTER B7 LOAD CENTER B9 EV LEARN LOAD CENTER BUS
9 EA01 TXL 0.5 BN/YE FUEL PUMP 3 DIAGNOSTIC PWR E FUEL PUMP CONTROL
10 EA02 TXL 0.5 BN/RD ECU_CNA 2 OIL PUMP B OIL PUMP CONTROL
11 EA03 TXL 0.5 DB/WH ECU_CNA 3 EV ACTUATOR 2 EXHAUST VALVE SET PWM
12 EA05 TXL 0.5 OG/DG ECU_CNA 5 LOAD CENTER C5 BATTERY CHARGE RELAY CONTROL
13 EA06 TXL 0.5 GY/YE ECU_CNA 6 LOAD CENTER C9 EV ACTUATOR RELAY CONTROL
14 EA09 TXL 0.5 OG LOAD CENTER D7 ECU_CNA 9 EXTERNAL PWR
15 EA09-1 TXL 0.8 OG DIAGNOSTIC PWR A LOAD CENTER D7 EXTERNAL PWR
16 EA10 TXL 0.5 BK ECU_CNA 10 SPLICE,HARD STOP 1 HARD STOP
17 EA10-1 TXL 0.5 BK SPLICE,HARD STOP 2 TETHER SWITCH 1 HARD STOP
18 EA10-2 TXL 0.5 BK CHASSIS/HOOD 14 SPLICE,HARD STOP 2 HARD STOP
19 EA10-3 TXL 0.5 BK HARD STOP SWITCH P1 SPLICE,HARD STOP 2 HARD STOP
20 EA11 TXL 0.5 GY ECU_CNA 11 REVERSE SW P1 REVERSE SIGNAL
21 EA12 TXL 0.5 VT ECU_CNA 12 OIL LEVEL P1 OIL SW
22 EA13 TXL 0.5 OG/BK ECU_CNA 13 BRAKE SWITCH SPLICE 2 BRAKE SW
23 EA17 TXL 0.5 DG/WH ECU_CNA 17 CHASSIS/HOOD 7 STARTER LOCKOUT
24 EA20 TXL 0.5 PK/RD ECU_CNA 20 FUEL SENSOR 4 FUEL TEMPERATURE
25 EA21 TXL 0.5 DG/YE ECU_CNA 21 FUEL SENSOR 2 FUEL PRESURE
26 EA22 TXL 0.5 DG/RD ECU_CNA 22 GROUND SPEED SENSOR B GROUND SPEED SIGNL
27 EA23 TXL 0.5 RD/WH SPLICE,CHASSIS POWER #1 1 ECU_CNA 23 CHASSIS PWR
28 EA24 TXL 0.5 PK/BK LOAD CENTER D3 ECU_CNA 24 BATTERY VOLTAGE
29 EA25 TXL 0.5 BN/WH ECU_CNA 25 SPLICE,PBR GROUND #1 1 ECU GND
30 EA26 TXL 0.5 DG/YE ECU_CNA 26 EV ACTUATOR 1 EXHAUST VALVE POSITION PWM
31 EA26-3 TXL 0.5 OG/WH GROUND SPEED SENSOR A GROUND SPEED CAPACITOR P1 SPEED SENSOR PWR
32 EA28-1 TXL 1.0 YE PBR (ECU,CAN,GND) P2 SPLICE,CAN HI 1 CAN HI
33 EA28-2 TXL 0.5TP YE SPLICE,CAN HI 2 DIGITAL WRENCH H CAN HI
34 EA28-3 TXL 0.5TP YE SPLICE,CAN HI 2 CHASSIS/HOOD 15 CAN HIGH
35 EA29-1 TXL 0.5TP DG SPLICE,CAN LOW 2 CHASSIS/HOOD 16 CAN LOW
36 EA29-2 TXL 0.5TP DG SPLICE,CAN LOW 2 DIGITAL WRENCH G CAN LOW
37 EA29-3 TXL 1.0 DG PBR (ECU,CAN,GND) P5 SPLICE,CAN LOW 1 CAN LOW
38 EA30 TXL 0.5 RD ECU_CNA 30 SPLICE,CRITICAL POWER #1 2 CRITICAL PWR
39 EA32 TXL 0.5 OG/WH ECU_CNA 32 GROUND SPEED CAPACITOR P1
SPEED SENSOR PWR
40 EA34 TXL 0.5 BK/DB ECU_CNA 34 SPLICE,CHASSIS SENSOR GROUND #2 1 SENSOR GND
41 EB01 TXL 0.5 YE/WH ECU_CNB 1 INJECTOR HARNESS 4 INJECTOR MAG
42 EB02 TXL 0.5 RD/DB ECU_CNB 2 INJECTOR HARNESS 3 INJECTOR PWR
43 EB03 TXL 0.5 DB/WH ECU_CNB 3 INJECTOR HARNESS 2 INJECTOR PTO
44 EB04 TXL 0.5 RD/DB ECU_CNB 4 INJECTOR HARNESS 1 INJECTOR PWR
45 EB05 TXL 0.5 WH ECU_CNB 5 STATOR SIGNALS P5 CPS (2T)
46 EB05-1 TXL 0.5 WH/RD STATOR SIGNALS P6 SPLICE,CPS LOW 2 CPS (LOW)
47 EB05-2 TXL 0.5 WH/DG STATOR SIGNALS P3 SPLICE,CPS LOW 2 CPS (LOW)
48 EB06 TXL 0.5 DG ECU_CNB 6 STATOR SIGNALS P2 CPS (5T)
49 EB07 TXL 0.5 WH/RD ECU_CNB 7 SPLICE,CPS LOW 1 CPS (LOW)
50 EB08 TXL 0.5 BK/YE IGN GND SPLICE 2 ECU_CNB 8 IGNITION - (MAG)
51 EB08-1 TXL 0.5 BK IGN GND SPLICE 2 STATOR SIGNALS P4 ENG GND
52 EB08-2 TXL 0.5 BK/YE IGN GND SPLICE 1 IGNITION COIL (MAG) P2 IGN - (MAG)
53 EB09 TXL 0.5 YE/BK IGNITION COIL (MAG) P1 ECU_CNB 9 IGN + (MAG)
54 EB10 TXL 0.5 RD/DB ECU_CNB 10 INJECTOR PWR SPLICE 1 INJECTOR PWR
55 EB10-1 TXL 0.8 RD/DB LOAD CENTER D6 INJECTOR PWR SPLICE 1 EXTERNAL PWR
56 EB10-2 TXL 1.0 RD/DB LOAD CENTER B3 INJECTOR PWR SPLICE 1 INJECTOR PWR
57 EB10-3 TXL 2.0 RD/DB INJECTOR PWR SPLICE 2 PBR (DC POWER) P2 INJECTOR PWR SENSE
58 EB10-4 TXL 0.5 RD/DB DIGITAL WRENCH A INJECTOR PWR SPLICE 2 INJECTOR PWR
59 EB11 TXL 0.5 GY ECU_CNB 11 TMAP SENSOR 4 INTAKE AIR PRESSURE SIGNAL
60 EB12 TXL 0.5 PK ECU_CNB 12 TMAP SENSOR 2 INTAKE AIR TEMP SIGNAL
61 EB13 TXL 0.5 BU ECU_CNB 13 TPS SENSOR B TPS SIGNAL
62 EB14 TXL 0.5 VT ECU_CNB 14 DETONATION SENSOR 2 DET SIGNAL
63 EB15 TXL 0.5 BK/WH ECU_CNB 15 DETONATION SENSOR 1 DET SENSOR GND
64 EB16 TXL 0.5 BK/DB IGN GND SPLICE 2 ECU_CNB 16 IGNITION - (PTO)
65 EB16-1 TXL 0.5 BK/YE IGNITION COIL (PTO) P2 IGN GND SPLICE 1 IGN - (PTO)
66 EB17 TXL 0.5 OG/YE ECU_CNB 17 IGNITION COIL (PTO) P1 IGN + (PTO)
67 EB18 TXL 0.5 BN/WH SPLICE,PBR GROUND #1 1 ECU_CNB 18 ECU GND
68 EB19 TXL 0.5 YE/RD ECU_CNB 19 COOLANT TEMP SENSOR P2 COOLANT TEMP SIGNAL
69 EB20 TXL 0.5 WH/BK ECU_CNB 20 EGT SENSOR A EGT SIGNAL
70 EB21 TXL 0.5 YE/VT ECU_CNB 21 EGT2 A EGT2
71 EB24 TXL 0.5 BK/RD ECU_CNB 24 SOFT STOP SWITCH P2 SOFT STOP
72 EB26 TXL 0.5TP YE ECU_CNB 26 DIGITAL WRENCH E CAN2 HI
73 EB27 TXL 0.5TP DG ECU_CNB 27 DIGITAL WRENCH F CAN2 LO
74 EB28 TXL 0.5TP YE SPLICE,CAN HI 1 ECU_CNB 28 CAN HI
75 EB29 TXL 0.5TP DG SPLICE,CAN LOW 1 ECU_CNB 29 CAN LOW
76 EB30 TXL 0.5 RD/WH ECU_CNB 30 SPLICE,SENSOR POWER #1 1 SENSOR PWR
77 EB30-1 TXL 0.5 RD/WH SPLICE,SENSOR POWER #1 2 TMAP SENSOR 3 SENSOR PWR
78 EB30-2 TXL 0.5 RD/WH SPLICE,SENSOR POWER #1 2 TPS SENSOR A SENSOR PWR
79 EB30-3 TXL 0.5 RD/WH SPLICE,SENSOR POWER #1 1 FUEL SENSOR 1
SENSOR PWR
80 EB31 TXL 0.5 BK/DB ECU_CNB 31 SPLICE,CHASSIS SENSOR GROUND #3 1 SENSOR GND
81 EB31-1 TXL 0.5 BK/DB SPLICE,CHASSIS SENSOR GROUND #3 1 TPS SENSOR C SENSOR GND
82 EB31-2 TXL 0.5 BK/DB SPLICE,CHASSIS SENSOR GROUND #3 2 EGT SENSOR B SENSOR GND
83 EB31-3 TXL 0.5 BK/DB SPLICE,CHASSIS SENSOR GROUND #3 2 COOLANT TEMP SENSOR P1 SENSOR GND
84 EB31-4 TXL 0.5 BK/DB SPLICE,CHASSIS SENSOR GROUND #3 2 TMAP SENSOR 1 SENSOR GND
85 EB31-6 TXL 0.5 BK/DB SPLICE,CHASSIS SENSOR GROUND #3 1 EGT2 B SENSOR GND
86 GC01 TXL 3.0 BN PBR (ECU,CAN,GND) P1 SPLICE,PBR GROUND #1 2 CHASSIS GND
87 GC02 TXL 3.0 BN PBR (ECU,CAN,GND) P4 SPLICE,PBR GROUND #1 1 CHASSIS GND
88 GC03 TXL 3.0 BN PBR (ECU,CAN,GND) P3 SPLICE,PBR GROUND #1 1 CHASSIS GND
89 GC04 TXL 5.0 BN CHASSIS GROUND 1 SPLICE,PBR GROUND #1 2 CHASSIS GND
90 GC05 TXL 0.8 BN/WH SPLICE,PBR GROUND #1 2 SPLICE,ECU GROUND 1 ENGINE GND
91 GC06 TXL 0.8 BN TAIL LIGHT C SPLICE,DC CHASSIS GROUND 2 CHASSIS GND
92 GC08 TXL 3.0 BN CHASSIS GROUND 1 BATT GND 2 CHASSIS GND
93 GC08-1 TXL 1.0 BN BATT GND 1 ELECTRIC START 3 CHASSIS GND
94 GC08-2 TXL 1.0 BN BATT GND 1 ELECTRIC START 2 CHASSIS GND
95 GC08-3 TXL 1.0 BN BATT GND 1 ELECTRIC START 1 CHASSIS GND
96 GC09 TXL 1.0 BN CHASSIS GROUND 1 DIAGNOSTIC PWR F CHASSIS GND
97 GC12 TXL 1.0 BN SPLICE,DC CHASSIS GROUND 1 CHASSIS GROUND 1 CHASSIS GND
98 GC15 TXL 0.8 BN SPLICE,DC CHASSIS GROUND 1 CHASSIS/HOOD 8 CHASSIS GND
99 GC19 TXL 0.8 BN SPLICE,DC CHASSIS GROUND 1 SPLICE,HANDWARMER GROUND 1 CHASSIS GND
100 GC21 TXL 0.5 BN SPLICE,DC CHASSIS GROUND 2 CONSOLE JUMPER D CHASSIS GND
101 GC22 TXL 0.8 BN SPLICE,DC CHASSIS GROUND 2 RCA ACCESSORY POWER B CHASSIS GND
102 GC23 TXL 0.8 BN THUMBWARMER C SPLICE,HANDWARMER GROUND 1 CHASSIS GND
103 GC24 TXL 0.8 BN RIGHT HANDWARMER C SPLICE,HANDWARMER GROUND 2 CHASSIS GND
104 GC25 TXL 0.8 BN LEFT HANDWARMER C SPLICE,HANDWARMER GROUND 2 CHASSIS GND
105 GC26 TXL 0.8 BN/YE DIAGNOSTIC PWR TEST JUMPER F DIAGNOSTIC PWR TEST JUMPER E CHASSIS GND
106 GE01 TXL 0.8 BN/WH SPLICE,ECU GROUND 2 CHASSIS GROUND 1 CHASSIS GND
107 GE02 TXL 0.5 BN/WH SPLICE,ECU GROUND 2 GROUND SPEED CAPACITOR P2 ECU GND
108 GE03 TXL 0.8 BN/WH CHASSIS/HOOD 3 FUEL PUMP 4 ECU GND
109 GE04 TXL 1.0 BN/WH EV ACTUATOR 4 SPLICE,ECU GROUND 2 ECU GND
110 GE05 TXL 0.5 BN/WH OIL LEVEL P2 SPLICE,ECU GROUND 1 ECU GND
111 GE08 TXL 0.8 BN/WH GROUND SPEED SENSOR C GROUND SPEED CAPACITOR P2 ECU GND
112 GS01 TXL 0.8 BK/DB SPLICE,CHASSIS SENSOR GROUND #1 2 DIGITAL WRENCH D SENSOR GND
113 GS02 TXL 0.8 BK/DB SPLICE,CHASSIS SENSOR GROUND #1 1 SPLICE,CHASSIS SENSOR GROUND #2 1 SENSOR GND
114 GS03 TXL 0.8 BK/DB SPLICE,CHASSIS SENSOR GROUND #2 2 TETHER SWITCH 2 SENSOR GND
115 GS04 TXL 0.8 BK/DB CHASSIS/HOOD 13 SPLICE,CHASSIS SENSOR GROUND #2 2 SENSOR GND
116 GS05 TXL 0.8 BK/DB SPLICE,CHASSIS SENSOR GROUND #2 1 SOFT STOP SWITCH P1 SENSOR GND
117 GS06 TXL 0.8 BK/DB HARD STOP SWITCH P2 SPLICE,CHASSIS SENSOR GROUND #2 2 SENSOR GND
118 GS07 TXL 0.5 BK/DB REVERSE SW P2 SPLICE,CHASSIS SENSOR GROUND #1 2 SENSOR GND
119 GS08 TXL 0.5 BK/DB SPLICE,CHASSIS SENSOR GROUND #1 1 FUEL SENSOR 3
SENSOR GND
120 PBATT01 TXL 0.8 PK/BK ELECTRIC START 8 SPLICE,BATTERY POWER 1 FUSED BATTERY PWR
121 PBATT03 TXL 0.8 PK/BK SPLICE,BATTERY POWER 2 LOAD CENTER D3 FUSED BATTERY PWR
122 PBATT04 TXL 0.5 PK/WH LOAD CENTER D2 CHASSIS/HOOD 11 GAUGE BATTERY PWR
123 PCH01 TXL 2.0 RD/WH PBR (DC POWER) P1 SPLICE,CHASSIS POWER #1 2 CHASSIS PWR
124 PCH02 TXL 2.0 RD/WH SPLICE,CHASSIS POWER #1 2 LOAD CENTER A3 CHASSIS PWR
125 PCH03 TXL 2.0 RD/WH SPLICE,CHASSIS POWER #1 1 DIAGNOSTIC PWR D CHASSIS PWR
126 PCH04 TXL 2.0 RD/WH SPLICE,CHASSIS POWER #1 1 LOAD CENTER C4 CHASSIS PWR
127 PCH06 TXL 0.8 RD/WH SPLICE,ACCESSORY POWER 2 LOAD CENTER A4 FUSED ACC PWR
128 PCH08 TXL 0.8 RD/WH SPLICE,ACCESSORY POWER 1 CHASSIS/HOOD 5 HOOD ACC PWR
129 PCH09 TXL 0.8 RD/WH RCA ACCESSORY POWER A SPLICE,ACCESSORY POWER 1 RCA ACC PWR
130 PCH12 TXL 0.8 RD/WH CONSOLE JUMPER H LOAD CENTER A6 FUSED DRIVER CHASSIS PWR
131 PCH18 TXL 0.8 DB SPLICE,HANDWARMER HIGH 1 CONSOLE JUMPER J HIGH HW PWR
132 PCH19 TXL 0.8 DB/RD SPLICE,HANDWARMER LOW 1 CONSOLE JUMPER K LOW HW PWR
133 PCH20 TXL 0.8 DB RIGHT HANDWARMER A SPLICE,HANDWARMER HIGH 2 HIGH HW PWR
134 PCH21 TXL 0.8 DB LEFT HANDWARMER A SPLICE,HANDWARMER HIGH 2 HIGH HW PWR
135 PCH22 TXL 0.8 DB/RD RIGHT HANDWARMER B SPLICE,HANDWARMER LOW 2 LOW HW PWR
136 PCH23 TXL 0.8 DB/RD LEFT HANDWARMER B SPLICE,HANDWARMER LOW 2 LOW HW PWR
137 PCH24 TXL 0.8 GY/WH THUMBWARMER B CONSOLE JUMPER F HIGH THUMBWARMER PWR
138 PCH25 TXL 0.8 OG/DG THUMBWARMER A CONSOLE JUMPER G LOW THUMBWARMER PWR
139 PCH30 TXL 2.0 RD/YE LOAD CENTER D5 BATT CHARGE SPLICE 2 CHASSIS PWR
140 PCH30-1 TXL 1.0 RD/YE BATT CHARGE SPLICE 1 ELECTRIC START 7 BATTERY CHARGING
141 PCH30-2 TXL 1.0 RD/YE BATT CHARGE SPLICE 1 ELECTRIC START 6 BATTERY CHARGING
142 PCH30-3 TXL 1.0 RD/YE BATT CHARGE SPLICE 1 ELECTRIC START 5 BATTERY CHARGING
143 PCR01 TXL 2.0 RD PBR (DC POWER) P3 SPLICE,CRITICAL POWER #1 1 CRITICAL PWR
144 PCR02 TXL 1.0 RD SPLICE,CRITICAL POWER #1 2 SPLICE,CRITICAL POWER #2 1 CRITICAL PWR
145 PCR03 TXL 0.8 RD SPLICE,CRITICAL POWER #1 1 LOAD CENTER C8 CRITICAL PWR
146 PCR03-1 TXL 0.5 RD LOAD CENTER C8 LOAD CENTER D8 CRITICAL PWR
147 PCR03-2 TXL 0.5 RD LOAD CENTER D4 LOAD CENTER D8 CRITICAL PWR
148 PCR04 TXL 0.8 OG/BK BRAKE SWITCH SPLICE 1 TAIL LIGHT B BRAKE SW
149 PCR05 TXL 1.0 RD SPLICE,CRITICAL POWER #1 2 DIAGNOSTIC PWR B CRITICAL PWR
150 PCR06 TXL 0.8 RD/BK CHASSIS/HOOD 9 LOAD CENTER C2 CRITICAL PWR - GAUGE
151 PCR07 TXL 0.8 RD OIL PUMP A SPLICE,CRITICAL POWER #2 2 CRITICAL PWR
152 PCR08 TXL 0.8 RD FUEL PUMP 1 SPLICE,CRITICAL POWER #2 2 CRITICAL PWR
153 PCR10 TXL 0.8 RD/BK LOAD CENTER D9 LOAD CENTER B9 BRAKE LIGHT PWR
154 PCR11 TXL 0.8 RD/BK BRAKE SWITCH 1 LOAD CENTER B8 FUSED BRAKE LIGHT PWR
155 PCR12 TXL 0.8 RD/BK EV ACTUATOR 3 LOAD CENTER B6 EV ACTUATOR PWR
156 PCR14 TXL 0.8 RD/BK LOAD CENTER C3 LOAD CENTER B4 FUSED GAUGE PWR
157 PCR15 TXL 0.8 RD/BK SPLICE,LIGHT POWER 1 LOAD CENTER B4 FUSED LIGHT PWR
158 PCR16 TXL 0.8 RD/BK CONSOLE JUMPER B SPLICE,LIGHT POWER 2 HIGH BEAM PWR
159 PCR17 TXL 0.8 RD/BK SPLICE,LIGHT POWER 2 CHASSIS/HOOD 2
LOW BEAM PWR
160 PCR18 TXL 0.8 RD/BK SPLICE,LIGHT POWER 2 TAIL LIGHT A TAIL LIGHT PWR
161 PCR19 TXL 0.8 OG/BK BRAKE SWITCH 2 BRAKE SWITCH SPLICE 1 BRAKE SIGNAL
162 PCR20 TXL 0.8 YE/RD CHASSIS/HOOD 1 CONSOLE JUMPER A HIGH BEAM HEADLIGHT PWR
163 PCR21 TXL 0.8 RD/BK LOAD CENTER D9 DIAGNOSTIC PWR C GAUGE TEST PWR
164 PE01 TXL 2.0 OG PBR (ECU,CAN,GND) P6 LOAD CENTER B2 ECU PWR
09/20/18
WIRE COLOR LEGEND
BG
BK
BU
DB
BN
GY
GN
DG
OG
PK
RD
VT
WH
YE
BEIGE (TAN)
BLACK
LIGHT BLUE
DARK BLUE
BROWN
GRAY
LIGHT GREEN
DARK GREEN
ORANGE
PINK
RED
VIOLET (PURPLE)
WHITE
YELLOW
TWO WIRE COLORS ARE SHOWN
WITH MAIN/TRACE COLORS.
EXAMPLE:RD/YE = RED WITH
YELLOW TRACE.
Critical Power - 850 Long Track
E = ENGINE GROUND
C = CHASSIS GROUND
NC = SWITCH NORMALLY CLOSED
NO = SWITCH NORMALLY OPEN
CL CLEAR
To Next Page
Loading...
Need help?
General
