Table 5-3. Operational Error Messages (Cont'd)
Hex Code Error Definition Probable Cause Action
00 00 80 00 (Cont'd) • Improperly connected cable from
power supply to J5 on main
controller PC board.
• Improperly connected ribbon
cable from main controller PC
board to sensor (CCD) PC
board.
Note: If all else fails, replace
main controller and/or
sensor (CCD) PC
boards.
01 00 00 00 DSPTIMEOUT: Defective Main Replace Main
DSP communications Controller PC Board. Controller PC Board.
to slide scanner timed
out.
02 00 00 00 DSPFLTERROR: Defective Main Replace Main
DSP communications Controller PC Board. Controller PC Board.
to slide scanner has
faulted.
04 00 00 00 DSPSYNCERROR: Defective Main Replace Main
DSP lost Controller PC Board. Controller PC Board.
synchronization t
during acquisition.
08 00 00 00 DSPSTATUSERROR: Defective Main Replace Main
DSP has a Status Controller PC Board. Controller PC Board.
error from last
operation.
10 00 00 00 DSPBADSTATUS: Defective Main Replace Main
DSP communications Controller PC Board. Controller PC Board.
to slide scanner is
out of synchronization.
*
*
SprintScan PLUS only.
* * Not Used in SprintScan PLUS.
