Slide Scanner Repair Manual Diagnostics and Troubleshooting
140
Table 5-10. Interpreting Measurements of the Color Registration & Motion Tests
Test Name Specification Suggested Repair
SS35 ES & Plus
Mean R->B Less than 0.64 pixels Refer to Motion Analysis and Results in
Vert Offset the previous paragraphs.
(Pixels)
Mean R->B Less than 0.64 pixels Refer to Motion Analysis and Results in
Horiz. Offset the previous paragraphs.
(Pixels)
Mean Offset Less than 0.707 pixels Refer to Motion Analysis and Results in
(RSS Pixels) the previous paragraphs.
Peak R-B 1.1 pixels or less Refer to Motion Analysis and Results in
Misalignment the previous paragraphs.
(Pixels)
Estimated CCD None Information only.
Tilt (Degrees)
Best Mag Time None Information only.
Change (usec)
RMS Vertical Motion None Information only.
Error (Pixels)
RMS Horizontal None Information only.
Motion (Pixels)
Peak Swing None Information only.
Misalignment
(Pixels)
