Polaroid SprintScan SS35 User Manual

30
Slide Scanner Repair Manual Scanner Overview
Check and adjust, if
necessary:
• Base line integration time
to ensure a minimum signal
and mitigation of saturation
• Analog gain and offset for
base line neutral settings
• Digital uniformity
offset calibration
• Digital uniformity
gain calibration
• Bad pixel identification
• Drift test (lamp/front end)
Figure 1-9. Calibration simplified flow diagram
Calibration
Completed
Ready LED
Lights Steady
Run LabVIEW Test
(See Section 5 for Details)
Ready LED
Continually Blinks
Start Scan
SS35 PLUS Calibration
Routine
Calibrate
Scan
Fail
Pass
No Scan

Polaroid SprintScan SS35 Specifications

General

Brand	Polaroid
Model	SprintScan SS35
Category	Scanner
Language	English
