Custom Data Plot Menu
♥ (Heartbeat)
Pulses on and off to indicate that the system is powered on (power
status).
75%
Percentage of battery life remaining.
C: 603
Current measurement of CO
2
Concentration (ppm).
Delay/CAL/END
Delay is the countdown in seconds from x to 0, where x is the Delay
value specified in Custom – Termination Settings (Step 3). CAL is the
active CO
2
concentration calculating phase. END indicates calculations
have been terminated.
dC
The current difference in CO
2
concentration (ppm) from time = 0
seconds.
dT
Elapsed time (seconds) for the current session (i.e., change in time).
L
Linear respiration rate (g m
-2
hour
-1
).
Q
Quadratic respiration rate (g m
-2
hour
-1
).
Plot
Plot number defined by user in Custom – Other Settings (Step 4).
X-axis
Time (1 second interval)
Y-axis
dC (change in CO
2
concentration)(ppm)
maxDC
Maximum negative change in CO
2
concentration (ppm) allowed in a
given session. This value is defined in Custom – Termination Settings
(Step 3).
maxDT
Maximum time for which changes in the chamber CO
2
concentration are
monitored in a given session. This value is defined in Custom –
Termination Settings (Step 3).
Abort Button
Stops the Custom process and returns to Custom – Other Settings (Step
4). Only the individual CO2 measurements are saved to the USB flash
drive. Process data is discarded.
Status Box
Any information or error messages are displayed here.
New Button
Stops the Custom process and returns to Custom – Other Settings (Step
4). Results are saved to the USB flash drive.
