General Information
The following information provides general equipment and service information that will help
you to use this manual to properly repair and maintain the elliptical.
Features
The equipment operating specifications.
Feature Specification
Consoles
R20 and R40 consoles
*R40 supports smart phone charging.
CrossRamp Incline 15-40 degs, 20 levels
Stride Length Stride Length 21-24" (53-61 cm)
Resistance 625 Watts, 20 levels
Lift Motor Actuator
115 Vac (range: 90-132 Vac), 50/60 Hz
1
nominal
Internal Thermal Protection, auto reset
Stroke: 2"-23" (5-60 cm)
External Load: max 1.300 lb (590 Kgs
Linear Speed: 19 in/min (48 cm/min
Position Potentiometer: Wiper, Linear taper, Total Reistance
1,000 ohms
Heart Rate
Two Heart Rate sensor types:
l
Touch Handheld Handlebar Heart Rate sensors (HHHR
2
).
l
Telemetry equipped for wireless chest strap heart rate mon-
itoring.
Power 120V, 60Hz, dedicated 15A circuit
Max User Weight Maximum exerciser weight: 350 lbs (159 kgs)
Dimension/Weight
Weight: 240 lb / 109 kg
Dimensions:
L 84 in X W 31 in X H 67 in
L 213 cm X W 79 cm X H 171 cm
1
The hertz (symbol: Hz) is the derived unit of frequency in the International System of Units
(SI) and is defined as one cycle per second.
2
Handheld Handlebar Heart Rate
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 6
