System Component Specification
Set screws 300 in-lbs (34 Nm)
Plastite screw fasteners 20 in-lbs (2.3 Nm)
Flathead screws 25 in-lbs (2.8 Nm)
Idler Pulley Bolt 120in-lbs (13.6 Nm)
Input Belt Tension Bolt 200 in-lbs (17 ft-lbs, 22.6 Nm)
Lift Yoke Mounting Bolts 240 in-lbs (20 ft-lbs, 27 Nm)
Pillow Block Mounting Bolts 120 in-lbs (10 ft-lbs, 13.6 Nm)
Eddy Current Magnet Mounting Bolts 66 in-lbs (7.5 Nm)
Crank Arm Mouinting Bolt 300 in-lbs (25 ft-lbs, 34 Nm)
Step-up Pulley Axle Nut 480 in-lbs (40 ft-lbs, 54.2 Nm)
Stairarm Pivot Block Mounting Bolt 180 in-lbs (15 ft-lbs, 20.3 Nm)
Stairarm Wheel Assembly Screws 60 in-lbs (6.8 Nm)
Ramp Bracket To Frame Bolts 480 in-lbs (40 ft-lbs, 54.2 Nm)
Ramp Bracket To Ramp Screws 144 in-lbs (12 ft-lbs, 16.3 Nm)
Lift Motor Lower Mounting Bolt 60 in-lbs (6.8 Nm)
Calibration Specification
System calibration specification:
System Component Specification
Lift Motor Jackscrew Calibration Distance 1 in (2.54 cm)
Incline Level A/D
1
Calibration Incline angle A/D values:
l
Nominal value: 13 ±5 @ -2%
incline
l
Nominal value: 37 ±5 @0%
incline
l
Nominal value: 242 ±5 @ 15%
incline
1
analog to digital converter
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 12
