Videos
Service Video Link
EFX400 Lift Motor Replace Lift Motor Replacement
Procedure
Review entire procedure before starting.
WARNING:Care must be taken when work is being performed in the area of the
stairarms. Pinch points exist between the stairarm and ramp and between the
stairarm and crankarm, when the rear covers are removed.
Removal
1. Switch the power “ON”.
2. Raise the incline to level 20.
3. Switch the power "OFF".
4. Remove the lift cover magazine rack and front lift covers (see ).
5. Remove the two ramp yoke mounting bolts and disconnect the lift yoke from the cross-
ramp. Carefully pull the yoke from under the ramp and then lower the ramp resting on
the back lift cover. Return the yoke into the back lift cover yoke slot. Retain part(s)
and/or fastener(s) for installation.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 205
6 Available Replacement Procedures
Lift Yoke Assembly Replacement
