Moving Arm Replacement
This procedure provides instruction to replace the Moving Arm.
Procedure
Review entire procedure before starting.
WARNING:Care must be taken when work is being performed in the area of the
stairarms. Pinch points exist between the stairarm and ramp and between the
stairarm and crankarm, when the rear covers are removed.
Removal
1. Switch the power OFF and unplug
1
the power cord.
2. Remove two bolts that fasten the forward end of the Connecting Lower Link to the
Moving Arm. Retain part(s) and/or fastener(s) for installation.
1
Disconnect a device power cord plug or cable connector from the power receptacle or out-
let.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 175
6 Available Replacement Procedures
Moving Arm Replacement
