Rear Drive covers
This procedure replaces the following rear drive assembly covers:
l
Drive cover access panel
l
Drive top cover
l
Drive side covers
l
Wedge cover
l
Drive front cover
l
Drive bottom cover
Remove
1. Reach inside either (left or right side) stairarm drive cover front slot and locate one of
the access panel anchors. Gently, press upwards on the access panel anchor to
unsnap the access panel from the drive top cover. Grasp the raised edge of the
access panel and lift to remove. You may need to push up on additional anchors to
help release the access panel cover.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 81
6 Available Replacement Procedures
Covers and Panels Replacement
