Pillow Block Bearing Replacement
This procedure provides instruction to replace the Pillow Block Bearing assembly.
Procedure
Review entire procedure before starting.
WARNING:Care must be taken when work is being performed in the area of the
stairarms. Pinch points exist between the stairarm and ramp and between the
stairarm and crankarm, when the rear covers are removed.
Specialized Tools
TOOL PN DESCRIPTION
PPP000000058197102* EFX400 PILLOW BLOCK REPLACEMENT TOOL KIT
Contents:
•(2x) PPP000000304277101 "DRIVE ASSY
1
COMPRESSION TOOL SIDE BAR"
•(1x) PPP000000304278101 "DRIVE ASSY
COMPRESSION TOOL - SPACER"
•(2x) PPP00000HCCN031700 " /16-18 X 7.00 BOLT
•(2x) PPP00000WBCN031007, FLAT WASHER
Note: * Purchase tool kit from Precor.customer service.
1
assembly
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 155
