Covers and Panels Replacement
This procedure provides instructions to remove/install the EFX400 covers and panels.
Cover Remove/lnstall Procedure
Top shroud display bracket Cover Top shroud display bracket Cover
Water Bottle Assy Covers Water Bottle Assy covers
Lift Covers "Lift covers" on page77
Magazine Rack Lift Cover "Lift covers" on page77
Front Lift Cover "Lift covers" on page77
Rear Drive Covers "Rear Drive covers" on page81
Drive cover access panel "Rear Drive covers" on page81
Drive top cover "Rear Drive covers" on page81
Drive side covers "Rear Drive covers" on page81
Wedge cover "Rear Drive covers" on page81
Drive front cover "Rear Drive covers" on page81
Drive bottom cover "Rear Drive covers" on page81
Water Bottle Assy covers
This procedure replaces the top shroud display bracket cover and water bottle assembly
covers.
Removal
1. Switch the power “OFF”, and unplug
1
the power cord.
Top shroud display bracket cover
2. Remove the 2 mounting screws and the Top Shroud Display Bracket cover.
1
Disconnect a device power cord plug or cable connector from the power receptacle or out-
let.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
