6. Remove the yoke. Grasp the lift motor jackscrew and unscrew the yoke to remove.
Retain part(s) and/or fastener(s) for installation.
TIP: Wear gloves or use a rag when holding the jackscrew to protect hands from
grease on the jackscrew.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 206
6 Available Replacement Procedures
Lift Yoke Assembly Replacement
