10. Install the lift motor into the lift motor connector bracket. Secure using one 3/16” hex
key wrench to hold the lift motor connector joint bolt (right side) while using a 3/16”
hex key socket to tighten the connector joint mounting nut (right side). Torque
1
the
bolt to 60 in-lbs (6.8 Nm).
1
Torque is a measure of the force that can cause an object to rotate about an axis. Bolt/nut
example: 5 NM torque is equivalent to 5 newton's of force applied one meter from the center
of the bolt, 6 ft-lb is equivalent to 6 lbs of force applied 1 foot away from the center of the
bolt.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 199
6 Available Replacement Procedures
Lift Motor Replacement
