Illustrations of Printer Components
243
Item
No.
Part No. Description Notes
1 Ref Setscrew (2) Part of item 25
2 Ref Bracket, Platen (2) Part of item 25
3 150957-901 Ironer, Paper
4 Ref Screw, Thread-forming (3) 6-32x.25
5 174968-001 Ironer Bracket/Plate Field Kit
6 Ref Plate, Ironer Part of item 5
7 112657-901
163080-001
Platen Assembly
Platen Assembly, Elastomeric P50H3, P50H6, P52H6 only
8 Ref Washer, Flat (2) Part of item 25
9 Ref Screw (2) Part of item 11
10 Ref Washer, Flat #4 (2) Part of item 11
11 152417-901 Platen Switch Kit Includes items 9, 10, 19
12 Ref Screw, Socket Cap, 6-32x.75 Part of item 15
13 Ref Washer Part of item 15
14 Ref Nut Part of item 15
15 154650-001 Platen Lever Kit Includes items 12, 13, 14
16 Ref Spring, Extension 1.12L Part of item 25
17 Ref Link, Spring Part of item 25
18 Ref Bearing, Nylon .376 Part of item 25
19 Ref Bracket, Switch Mount Part of item 11
20 Ref Wear Saddle, Platen (2) Part of item 25
21 150703-902 Platen Pulley, Drive
22 Ref Screw, Socket Cap, 6-32x.44 Part of item 21
23 141516-901 Belt, Timing, .080 Pitch, .312 Wide Platen Open Belt
24 153488-001 Platen/Paper Feed Cover Kit Platen Open Belt Cover
shown
25 153430-001 Platen Hardware Kit Includes items 1, 2, 8, 16,
17, 18, 20, 26
26 Ref Platen Washer Part of item 25
