Printronix P5000 - Page 341

341
9. Pull the paper tray out until the holes in the rails permit access to the M3
buttonhead screws. (Figure 66.)
10. Loosen one turn (do not remove) the M3x6 screws securing the vertical
rails to the stacker base. Each rail is secured by two screws. (Figure 66.)
Figure 66. The Lower Screws in the Vertical Rails
M3x6 Buttonhead Screw
(Two on each rail)
Access Hole in
Tray Rail
