350
Appendix E Installing The Power Stacker
16. Position the elevator assembly at the bottom of the vertical rails. (Figure
77.)
17. Connect the elevator I/O cable to the elevator assembly and install the
two 4-40 x 1/4 inch screws, as shown in Figure 77.
Figure 77. The Elevator I/O Cable
Stacker I/O
Cable
Screw, 4-40x1/4,
Pan Head (2)
Vertical Rail
Elevator Assembly
