PrismJET 54 Gen2 OPERATION MANUAL Product overview
2.1 Names of parts and functions 25
6 Media cut groove Used to cut media straight.
7 Pressurizing rollers Installed inside of the front cover.
Press and hold the media when printing.
8 Platen Installed inside of the front cover.
Stabilizes the print side of the media.
9 Maintenance cover L Used to prevent the user from touching the inner mechanical section.
Open and close in the following cases.
• When cleaning around the print head.
• When cleaning the color sensor.
• When replacing the cutter.
It is normally closed.
10 Maintenance cover R Used to prevent the user from touching the inner mechanical section.
Open and close in the following cases.
• When cleaning the cleaning wiper.
• When cleaning around the capping unit.
• When replacing the cleaning wiper.
It is normally closed.
No. Name Function
