PRISMJET 54 Gen2 - Standard Rough Adjustment Pattern

Before using PrismJET 54 Gen2 OPERATION MANUAL
88 3.6 Adjust Print
3.6.3.2 Standard Rough Adjustment Pattern
Perform rough adjustment when the degree of misalignment is large.
Print rough adjustment pattern and register the set values.
1. Display the Standard Adjust Print menu on Operation panel in the same way as step 2 of
“
3.6.3.1 Standard Confirmation Pattern”.
2. Press the [+] key or [-] key to select “Adj.2: Rough Pattern”.
3. Press the [Enter] key on the operation panel.
• “Warming Up Skip ->E” is displayed on Operation panel.
CAUTION
• While “Warming Up” is displayed, do not touch Platen and Media guide. They
become very hot and you could burn yourself.
NOTE
• You can start printing during warming up.
4.4.8 Start Printing during Warm up
