PrismJET 54 Gen2 OPERATION MANUAL Before using
3.6 Adjust Print 81
3.6.3 Standard Adjust Print
Adjusts only the print mode in the user type setting which is currently set.
This menu is made up with the following menus.
Follow the procedure below to adjust print quality.
1. Print the confirmation pattern and check the amount of misalignment.
3.6.3.1 Standard Confirmation Pattern
2. Perform rough adjustment when the misalignment is large.
3.6.3.2 Standard Rough Adjustment Pattern
Perform micro adjustment when the misalignment is small.
3.6.3.3 Standard Micro Adjustment Pattern
NOTE
• Perform rough adjustment first when the degree of misalignment is difficult to determine.
3. Print the confirmation pattern and check if the printer is adjusted properly.
3.6.3.1 Standard Confirmation Pattern
4. If the printer is not adjusted, go back to Step 2.
NOTE
• When you are not satisfied with the result of rough adjustment, perform micro adjustment.
Menu Name Description Reference
Standard Confirmation
Pattern
Print the confirmation pattern and check the amount
of misalignment.
3.6.3.1 Standard Confirmation
Pattern
Standard Rough
Adjustment Pattern
Perform this adjustment when the misalignment is
large.
3.6.3.2 Standard Rough
Adjustment Pattern
Standard Micro
Adjustment Pattern
Perform this adjustment when the misalignment is
small.
3.6.3.3 Standard Micro
Adjustment Pattern
