PRISMJET 54 Gen2 - Standard Micro Adjustment Pattern

Before using PrismJET 54 Gen2 OPERATION MANUAL
92 3.6 Adjust Print
3.6.3.3 Standard Micro Adjustment Pattern
Perform micro adjustment when the degree of misalignment is small.
Print micro adjustment pattern and register the set values.
1. Display the Standard Adjust Print menu on Operation panel in the same way as step 2 of
“
3.6.3.1 Standard Confirmation Pattern”.
2. Press the [+] key or [-] key to select “Adj.3: Fine Pattern”.
3. Press the [Enter] key on the operation panel.
• “Warming Up Skip ->E” is displayed on Operation panel.
CAUTION
• While “Warming Up” is displayed, do not touch Platen and Media guide.
They become very hot and you could burn yourself.
NOTE
• You can start printing during warming up.
4.4.8 Start Printing during Warm up
