PrismJET 54 Gen2 OPERATION MANUAL Before using
3.6 Adjust Print 93
• An micro adjust print pattern is printed.
(Starts printing after warming up is complete.)
• For the micro adjustment pattern, the same patterns will be printed on both sides and center of
the media.
4. Check the both ends and the center of the print result that printed with Adjust pattern, and select the
number from 1 to 7 that is not out of alignment.
• “6” is selected in the next printing sample.
NOTE
• “4” is the current setting value.
• When the line is aligned, the bold line on its left side does not have a white vertical line in the
middle.
1234567
Pattern name
D
Not adequate Adequate
Not adequate
