Maintenance PrismJET 54 Gen2 OPERATION MANUAL
268 6.2 Cleaning the printer
6.2.7 Cleaning the color sensor
This section describes how to clean the color sensor.
(1) Time for cleaning
If you repeatedly failed to perform an auto print quality calibration (Adjust Print).
(2) Cleaning procedures
Follow the procedure below to clean the color sensor.
• Before cleaning the color sensor, read this procedure thoroughly to fully understand it, and clean
promptly and correctly.
• While cleaning around the capping unit, with the cap removed from the print head, therefore
cleaning must be done before the print head dries.
This operation should be done within 15 minutes.
If the operation lasts over 15 minutes, follow the Steps 8 and 9 to stop the operation and perform
head cleaning, then resume cleaning.
6.2.3 Head cleaning
• Use the cleaning stick to clean the color sensor.
For details of the cleaning stick, refer to “
8.3 Options/Supply list”.
• Failure to clean and maintain your printer may void the warranty.
1. If the printer is turned ON, make sure the following.
• Printing or other operations are not in progress.
• The operation panel display is Normal.
To Next Page
