PRISMJET 54 Gen2 - Page 296

Troubleshooting PrismJET 54 Gen2 OPERATION MANUAL
306 7.3 The media is jammed
4. Raise the media loading lever.
5. Pull the media to your side, and cut the torn part with cutting tools such as a razor blade.
No. Name
1 Media loading lever
No. Name
1 Razor blade
2 Roll media
1
2
1
