PrismJET 54 Gen2 OPERATION MANUAL Before using
3.4 Loading media 57
5. Set the scroller on the holder with the fixed media stopper on the ink cartridge slot side.
No. Name
1 Scroller
2 Fixed media stopper
3 Ink cartridge slots
4 Scroller holder
