PRISMJET 54 Gen2 - Page 49

PrismJET 54 Gen2 OPERATION MANUAL Before using
3.4 Loading media 59
3. Set the roll media to the media feed slot.
NOTE
• If the end of the roll media is not wound tightly, wind it tightly again, and then load it.
4. Open the front cover to pull out the roll media.
No. Name
1 Roll media
2 Media feed slot
No. Name
1 Front cover
2 Roll media
1
2
2
1
