Before using PrismJET 54 Gen2 OPERATION MANUAL
70 3.5 Test print
3.5.2 Nozzle check F
It is used to check whether there are any clogged heads, or missing or blurred prints.
Print a nozzle check pattern using all of the nozzles on the print head.
NOTE
• If the nozzle check result indicates that the checked points are blurred or missing, clean the head.
6.2.3 Head cleaning
Perform the nozzle check once again at the end of the work.
TIP
•Refer to the following for printing procedure.
3.5 Test print
•The printer information (date and time of printing, printer’s serial number, firmware version, Select Nozzle setting) is
printed on the nozzle check pattern.
OK
