Trinity F90+ user manual
11.4 SONY RX1R II CAMERA
11.4.1 RX1RII settings
1. Disconnect the payload compartment according to chapter 11.1.
2. Remove the battery dummy.
3. Insert the original camera battery. Make sure it is charged. Charging is possible via the supplied charger.
4. Turn on the camera using the on/off switch on top of the camera.
The screen of the camera will power up.
5. Change settings:
Default settings via camera hardware controls
Access the settings by switching to Manual Mode M with the control wheel on top of the Camera.
Exposure: 1/2000 s (a small control wheel on the camera hind top right).
Aperture: F4 (The F-Stop wheel on the camera lens).
Focus: MF manual focus (a small control wheel on the front of the camera).
Focus: ∞ (via the manual focus wheel on the camera lens).
Default settings via camera display menu
• Access the settings menu by selecting MENU.
• Change the Menu by pressing the camera wheel left and right.
• In order to access the sub menus please press .
• Navigate through the corresponding submenu by turning the camera wheel.
• To change the setting please use the silver button.
6. In order to save the settings please turn the camera off using the on-off switch on camera top. Wait for 3 seconds and
switch the camera on.
7. Turn the camera off again and disconnect the battery.
8. Insert the battery dummy.
9. Turn the camera on.
10. Connect the payload compartment to the UAV.
