Trinity F90+ user manual
03 TECHNICAL SPECIFICATIONS
TECHNICAL DATA LOCKED <60 MINUTES UNLOCKED 90+ MINUTES
1
1 Subject to export regu-
lation, may require export
permission.
2 Please be aware that the
ight time and max. wind
tolerance are reduced with
increasing ight altitude.
Depending on the weather
conditions; tested at 15° C
(59° F). For further details
read the user manual chapter
3.1.
3 Under optimal
conditions.
4 Please be aware that
the max. wind tolerance is
reduced with increasing ight
altitude.
5 Please follow the local
regulations for the maximum
allowed transmission power.
6 For outside temperature
< 10°(<50 °F):
• Heat up the battery to 25°C
(77 °F) for at least 5 hours
For outside temperature < 0°
(<32 °F):
• Heat up the battery to 25°C
(77 °F) for at least 5 hours
• The ight time will be redu-
ced to max. 70 minutes.
Max. Take-off Weight 5.0 kg (11.0 lbs) 5.0 kg (11.0 lbs)
Max. Flight Time <60 min 90+ min
1
Max. Range = Area 70 km = 500 ha 100 km = 700 ha
Maximum ight altitude (MSL) 4500 m (13123.4 ft)
2
4500 m (13123.4 ft)
2
Command and Control Range 5 – 7.5 km
3
(3.1 – 4.7 mi) 5 – 7.5 km
3
(3.1 – 4.7 mi)
Payload max. 700 g (1.54 lbs) max. 700 g (1.54 lbs)
Optimal Cruise Speed 17 m/s (33 kn) 17 m/s (33 kn)
Wind Tolerance (ground) up to 9 m/s (17.5 kn)
4
up to 9 m/s (17.5 kn)
4
Wind Tolerance (cruise) 12 m/s (23.3 kn) 12 m/s (23.3 kn)
Battery Capacity 12 Ah 12 Ah
Battery Weight 1.5 kg (3.3 lbs) 1.5 kg (3.3 lbs)
RC transmitter frequency 2.4 GHz 2.4 GHz
Telemetry link (QBase Modem) frequency 2.4 GHz 2.4 GHz
Telemetry link (QBase Modem) power max. 100 mW
5
max. 100 mW
5
Operating temperature range
-12 °C to 50 °C
(10.4 °F to 122 °F)
6
-12 °C to 50 °C
(10.4 °F to 122 °F)
6
Wingspan 2.394 m (7.85 ft) 2.394 m (7.85 ft)
Transport Case Dimension
1002 x 830 x 270 mm
(39.4 x 32.7 x 10.6 inch)
1002 x 830 x 270 mm
(39.4 x 32.7 x 10.6 inch)
Transport Case Weight (3 batteries) 22.3 kg (49.1 lbs) 22.3 kg (49.1 lbs)
