149
Trinity F90+ user manual
13.5.10 Check the control surfaces
Move the right stick to the sides to check the ailerons. Move the same stick up and down to check the elevator. If the stick con-
guration was changed, use the left stick to check the ailerons and the elevator.
Make sure the control surfaces are moving while moving the stick. Do not y if a control surface is not moving. See chapter 14.2
for
troubleshooting.
13.5.11 Arm
!!NEVER ARM AN AIRCRAFT WITH A DAMAGED PROPELLER!!
•
Due to safety reasons the UAV will turn off the motors automatically after 30 seconds if no button has been pressed.
• Make sure the motors are spinning freely. If the spinning of the motors emits an untypical sound, turn off the motors.
• Make sure all three motors are tilted 90° upwards. If not, turn off the system. Contact your reseller for further assistance.
Front alignment: tilted upwards
CORRECT
Rear alignment: tilted upwards
CORRECT
Inspection and repairs
13
