Trinity F90+ user manual
7.5.5 Updating the ESC
When a new ESC rmware becomes available the user is informed via QBase.
1. Start QBase.
2. Select Updates and select Search Updates.
3. Select Download to start downloading the Firmware.
4. Select Update and conrm with Yes.
5. The ESC Firmware Update opens.
6. Please follow the instructions of the ESC update. When requested please select the downloaded ESC rmware
(QSESC_ESC_S32K_..._.hex.bin) in the User > Documents > QBase > Firmware > ESC folder.
7. After the update please disconnect the battery from the UAV.
In order to validate the update please follow the following four steps.
8. Connect the QBase modem to your computer.
9.
Connect the battery to power up the UAV. The UAV connects to QBase automatical
ly.
10.
Select Updates and select Search Updates.
11.
Please conrm that the detected version corresponds with the newest version
