88
Trinity F90+ user manual
8.6 Step 6 – Set up ADS-B receiver
1. Insert a suction cup into the gimbaled mount.
2. Insert a microUSB cable into the pingUSB.
3. Connect the other end of the USB cable to your laptop or computer.
Please always hang up the pingUSB vertically.
8.7 Step 7 – Set up iBase
• Make sure the Micro SD card is inserted into iBase .
• Place the antenna of iBase on your desired reference point (make sure the an-
tenna center is exactly above the reference mark) or directly on top of the iBase.
It is recommended that the iBase is not shaded by objects (trees, buildings,...).
While logging, you should stay away (min. 5 meters) and not stand or run beside
it!
• Connect the power bank to the iBase via the USB cable.
(Please not: There is a gap between the iBase housing and the micro USB plug.
Do not connect the plug with force.)
• Switch on the power bank by pressing the power button.
The iBase will power up automatically (green LED).
The iBase Log le is created as soon as the iBase determines its position
within approx. 25 seconds after powered up (blue LED is blinking).
