54
Trinity F90+ user manual
7.3 PLANNING A PHOTOGRAMMETRY OR LIDAR MISSION
In order to display the planning view, choose New Mission or Load Mission in the Mission Menu.
Wind Settings
Manual SettingsAuto Settings
• Auto: Get the wind data online.
°
The wind is automatically updated as soon as the rst waypoint is dened
• Manual: Set the wind manually by selecting:
°
the corresponding BFT intensity in the dropdown menu
°
the current wind direction with -30/-5 or +5/+30
Mission Settings
• To be found in the top left corner
• Choose UAV and sensor
Link Loss Tolerance
If the RC link as well as the ight data link is lost
during the ight, the UAV returns to the link reestab-
lishing waypoint after the selected time expired.
Link Loss Loiter Time
At the link reestablishing waypoint, the UAV loiters for the selected time and
tries to reestablish the telemetry connection to QBase and the transmitter.
