QubicaAMF XLi EDGE Series User Manual

XLi EDGE Pinspotter
Section 4-3 Page 4.3-2 Rev. Date: 10/2016
Table 4.3-1, Lubrication Schedule
EVERY 25,000 FRAMES
Table/Table Drive
Oil/Grease
Figure
Spotting hook pivot bushings
Oil
4.3-3b
Upper spotting link assembly bushings
Oil
4.3-3b
Solenoid linkages
Oil
4.3-3b
Ball joint assemblies
Oil
4.3-3b
Cam lever shaft
Oil
4.3-3c
Roller arm assembly
Oil
4.3-3c
Crank housing
Oil
4.3-3c
Latch pivot
Oil
4.3-3c
Off-spot lever pivot
Oil
4.3-3c
Spring hanger pivot bolts
Oil
4.3-3c
Spring hook bushings
Oil
4.3-3d
Respot cell lever
Oil
4.3-5
Respot cell pivot points
Oil
4.3-5
Carburetor links
Oil
4.3-5
Pivot washers
Oil
4.3-5
Finger lever bushings
Oil
4.3-7a
Finger link
Oil
4.3-7a
Spot lever
Oil
4.3-7b
Front actuator assembly bushings
Oil
4.3-8
Front connecting link assembly bushings
Oil
4.3-8
Table spot and respot cams
Grease
4.3-3a
Shuttle cam
Grease
4.3-3a
Spot and respot cam follower bearing
Grease
4.3-3b
Spot and respot levers
Oil
4.3-3b
Shuttle cam follower
Grease
4.3-3c
Sweep/Sweep Drive
Oil/Grease
Figure
Linkage knuckles
Oil
4.3-4a
Linkage joints
Oil
4.3-4a
Sweep motor tie rod assembly
Oil
4.3.4b
Yoke Assembly
Oil/Grease
Figure
Rear leg bushings
Oil
4.3-6
Linkage rod pivot points
Oil
4.3-6
Front leg lower bushings
Oil
4.3-6
Shuttle pivot shaft sleeve bearings
Oil
4.3-9
Back End side plate front roller bearing bracket
Oil
4.3-11
EVERY 100,000
FRAMES
Table/Table Drive
Oil/Grease
Figure
Table drive eccentric assembly
Grease
4.3-3c
Cam ball
Grease
4.3-3c
Inside of clevis
Grease
4.3.3c
Table support weldment sleeve bearings
Oil
4.3-3d
Respot cell finger slots
Grease
4.3-5
Shifter link and cam link needle bearings
Grease
4.3-7a & b
Cam Link
Grease
4.3-7a
Shifter Link
Grease
4.3-7a
Actuator arm inside surface
Grease
4.3-7b
Sweep/Sweep Drive
Oil/Grease
Figure
Inside guide tube
Grease
4.3-4a
Miscellaneous
Oil/Grease
Figure
Shock absorber pivot pins
Oil
4.3-10
Back End side plate rear roller support bushing
Oil
4.3-11
