19. Attach the Table Drive Eccentric to the Table Drive Housing with the bolt. Tighten the bolt
completely and then back off 1/3 turn.
20. Install the locknut on the bolt, tightening the nut with a socket while holding the bolt with a
wrench.
21. Reassemble all components of the Table Drive Assembly including the Clevis and Rod End.
22. Install the Table Drive Assembly onto the Table Drive Shaft, centering the Clevis between the
Torque Tube arm forks where the Clevis sits, and tighten the nut and bolt that secures the Table
Drive Assembly to the Table Drive Shaft.
23. Check the bearing that supports the Torque Tube for excessive play or wear. Replace as needed.
24. Install the bolt and nut that secures the Clevis to the Torque Tube, capturing the bearing and
spacers and tighten the bolt and nut.
25. Crank the Table up slightly and remove the 2x4.
26. Return power to the pinspotter.
27. Run the Table through one complete cycle.
28. Run the Sweep and Table to the Home position.
29. Cycle the pinspotter and observe for correct operation.
30. If pins spot incorrectly, fall over, or if the Table is contacting the pin deck, then Table adjustments
are needed.
4.5.25 Service the Shuttle Rod Assembly
1. Run the Sweep to the 1
st
Guard position.
2. Remove power from the pinspotter. Follow the appropriate Lock out/Tag out procedures.
3. Remove pins from the Durabin Assembly.
4. Remove the spring from the rear of the Shuttle Assembly. Set it aside.
5. Remove the nuts and bolts that secure the Shuttle Rod Assembly to the Shuttle Operating Rod
Lever and the Front End Lever Assembly of the Shuttle Actuator, and remove the Shuttle Rod
Assembly from the pinspotter.
6. Insert a pin punch in the hole in the larger diameter tube off the Shuttle Rod Assembly. The pin
punch must pass thru the hole of the inner rod and out the other side of the large tube. The inner
rod can be turned to align the holes with a locking-type pliers or another pin punch in the hole in
the smaller diameter tube of the Shuttle Rod Assembly.
