QubicaAMF XLi EDGE Series - Ball Failed to Cycle Machine

QubicaAMF XLi EDGE Pinspotter
Section 4-6 Page 4.6-24 Rev. Date: 10/2016
4.6.4.3 PROBLEM: Ball failed to cycle machine.
Figure 4.6-23
START
NO
NO
NO
Machine turned on in
the “Practice without
Pins” mode at the
MCU?
Switch machine to Bowl
Mode at MCU.
YES
Ball trigger cable loose
or broken?
Repair or replace.
YES
Defective ball detector?
Replace detector.
YES
Defective chassis?
Replace chassis.
YES
