Section 4.2
Machine Adjustments
400-088-120-02 4.2-33 Rev. Date: 10/2016
4.2.7.3 Replacing Urethane Rivets
1. Remove any remaining sections of the broken rivet.
2. Lubricate the raised portion of the new rivet’s stem with liquid soap.
3. Push the rivet through the cushion assembly until about 1 inch protrudes through the back of
the wooden plank.
4. Insert the end of the urethane rivet protruding through the wooden plank into the hole near
the end of the belt installation tool (784-003-000).
5. Use the tool as a crank to pull on the rivet until the raised portion of the stem is pulled through
the back of the wooden plank. Trim the ends of the rivets along the bottom row as necessary
to prevent them from interfering with the passage of fallen pins.
4.2.7.4 Replacing Cushion Components
1. Remove all urethane rivets and replace worn or broken component of cushion assembly.
2. Stack the Cushion Cover (090-005-230) and Rubber Cushion (000-024-807 or 000-024-808) on
top of each other.
3. Pull new urethane cushion rivets through stack of Cushion Cover and Rubber Cushion. NOTE:
Using a mild soap on the urethane cushion rivets will ease assembly.
4. Place Curtain Assembly (000-026-450), Sponge Rubber Cushion Pad (000-022-770), and Plank
(000-024-795 or 000-024-796) on stack, and pull tails of urethane rivets through all holes. DO
NOT PULL RIVETS ALL THE WAY THROUGH ASSEMBLY UNTIL ALL RIVET TAILS ARE THROUGH
PLANK.
5. Working from the center of the plank to the ends, pull the urethane rivets through the cushion
plank using the belt installation tool (784-003-000).
4.2.8 PIN CONVEYOR BELT ADJUSTMENTS
4.2.8.1 Belt Removal Procedure
Turn OFF the machine being worked on as well as the machines on each
side of the machine being worked on while replacing the belt.
1. Remove the EDGE Performance Lift from backend. Refer to the EDGE Performance Lift PSP
Manual Supplement.
