Maintenance Procedures
400-088-120-02 Page 4.5-3 Rev. Date: 10/2016
5. Check the Pin Holders (cookies) for wear. Replace as needed.
6. Check for bent or broken bin straps. Replace as needed.
7. Check for bent tubes. Straighten or replace as needed.
8. Check for cracked or broken Shuttle Arm Brackets. Replace as needed.
9. Check for loose or missing hardware. Tighten or replace as needed.
10. Place the Shuttle in the slides, holding the Slide Bracket tight to the Shuttle, and tighten the bolts
and nuts holding the Slide Bracket to the rear frame of the Durabin.
11. Install the Shuttle Tension Spring.
12. Restore power to the pinspotter. Cycle the pinspotter and observe for correct Shuttle operation.
Adjust the Shuttle Rod as needed. If pins are not shuttling, decrease the Shuttle Rod length. If pins
are double shuttling, increase the Shuttle Rod length.
100,000 Frame Maintenance
4.5.6 Check the Alignment of the Spot and Respot Cams and Levers
1. Remove power from the pinspotter. Follow the appropriate Lock out/Tag out procedures.
2. Visually observe if the Spot Lever and Respot Lever Cam Followers are in alignment with the Spot
and Respot Cam surfaces. If not, visually observe if the Shuttle Lever Cam Follower is in alignment
with the Shuttle Cam surface. If not, the Table Drive Shaft may have moved.
3. To correct, loosen the Locking Collar by loosening the setscrew holding it to the shaft, and using a
punch and hammer at the hole, rotate the collar counterclockwise.
4. Carefully move the Table Drive Shaft until the Spot and Respot Lever Cam Followers are in
alignment with the Spot and Respot Cam surfaces. A block and hammer can be used to tap the shaft
into position.
5. Tighten the Bearing Locking Collar by rotating the collar clockwise using a punch and hammer at
the hole. Tighten the Locking Collar setscrew.
6. Check the alignment of Table Drive Clevis, centered between the forks of the Torque Tube. Adjust
if necessary.
7. Restore power and cycle the pinspotter. Observe for correct pinspotter operation.
