QubicaAMF XLi EDGE Pinspotter
Section 4.5 Page 4.5-6 Rev. Date: 10/2016
4.5.10 Check Light Ball Sensor Operation
Refer to the Positive Ball Lift Manual for information relating to this maintenance activity.
4.5.11 Clean the Distributor Assembly with a Water-Based Cleaner
Refer to the XLi EDGE Distributor Manual for information relating to this maintenance activity.
4.5.12 Service the Distributor Drive Shaft Assembly
Refer to the XLi EDGE Distributor Manual for information relating to this maintenance activity.
4.5.13 Service the Cushion Shock Assembly
1. Run the sweep to the 1
st
Guard position.
2. Remove power from the pinspotter. Follow the appropriate Lock out/Tag out procedures.
3. Remove the Cushion Shock Assembly from the Cushion Assembly by opening the "X" washer with
a pair of pliers and pushing the pin out of the hanger ear, shock grommet, and the Cushion Tube
Weldment. (To ease the removal of the pin, loosen the nuts and bolts attaching the hanger ear to
the Cushion Tube Weldment).
4. Remove the Cushion Shock Assembly from the Motor Mount Weldment by opening the "X"
washer with a pair of pliers, and pushing the pin out of the Motor Mount Weldment and Cushion
Shock Assembly grommet.
5. Check the grommets and bushings for damage or excessive wear. Replace as needed.
6. Lubricate the bushing and grommet using brake fluid only.
7. Remove the compression spring from the shock assembly by loosening the bolt holding the collar.
Slide the collar, spring, and spring seating washer off the shock.
8. Clamp the shock end only (not the piston housing) in a vise. Press the piston rod into the housing,
checking for binds and/or little-to-no resistance. Replace as needed.
9. Check the piston housing for dents or leaking fluid. Replace as needed.
10. Install the compression spring, collar, and spring seating washer.
11. Insert a 1/2-inch open-end wrench between the coils of the spring at the point where the piston
rod exits the piston housing so that the wrench jaws straddle the piston rod.
