QubicaAMF XLi EDGE Series - Sweep Does Not Knock All Pins into Pit

Troubleshooting
400-088-120-02 Page 4.6-21 Rev. Date: 10/2016
Section 4.6
4.6.3.11 PROBLEM: Sweep does not knock all pins into pit.
Figure 4.6-20
START
Does sweep miss pins
at extreme rear of deck
under manual
operation?
Lengthen connecting
rod assembly.
Check box beam
clearance after
adjustment.
Adjust sweep. Refer to
Section 4 for sweep
adjustments.
YES
