QubicaAMF XLi EDGE Series User Manual

QubicaAMF XLi EDGE Pinspotter
Section 4.4 Page 4.4-90 Rev. Date: 10/2016
Pinspotter
Every 200,000 Frames
Service the EDGE Performance Lift and Track/Chain Assembly (refer to the
EDGE Performance Lift Pinspotter Manual Supplement)
Service the Pit Conveyor Rollers and Pit Assembly (see subsection 4.5.20)
Service the Backend Motor & Gearbox (Sweep & Table) Brakes & Encoders
(refer to the XLi EDGE Motor & Gearbox Manual)
Every 400,000 Frames
Service the Positive Ball Lift (PBL) Assembly (refer to the Positive Ball Lift
(PBL) Manual)
Service the Light Ball Sensor (LBS) Assembly (refer to the Positive Ball Lift
(PBL) Manual)
Service the Distributor Assembly (refer to the XLi EDGE Distributor
Manual)
Service the Table Drive (see subsection 4.5.24)
Service the Shuttle Rod Assembly (see subsection 4.5.25)
Service the Shifter and Cam Link Needle Bearings (see subsection 4.5.26)
