QubicaAMF XLi EDGE Series User Manual

QubicaAMF XLi EDGE Pinspotter
Section 4.4 Page 4.4-86 Rev. Date: 10/2016
4.4.2 Preventive Maintenance Schedule
Pinspotter
Daily
Check the call sheets for the previous day, transfer calls to stop summary
Investigate / correct machines that have developed a malfunction
pattern.
Clean Positive Ball Lift (PBL) Belt with a dry rag
Clean Distributor Belt with a dry rag
Assign and record completed PM on the PM charts
Weekly
Inspect the Carrier Rails for correct installation direction (pointed end
down)
Inspect Kickout Springs (2 per machine) – missing, bent, or loose
Remove, launder, and install Ball Wipes and Dust Collector Cloths
Inspect Distributor, observe for proper operation, correct as needed
Clean Durabin and Shuttle with a vinyl type dressing
Clean O-Pan and Distributor Funnels with a vinyl type dressing
