QubicaAMF XLi EDGE Series - Cushion and Pit Troubleshooting; Ball Idles at Cushion

QubicaAMF XLi EDGE Pinspotter
Section 4-6 Page 4.6-22 Rev. Date: 10/2016
4.6.4 Cushion and Pit Troubleshooting
4.6.4.1 PROBLEM: Ball idles at cushion.
Figure 4.6-21
Repair or replace
support bracket.
START
Cushion facing
stretched?
Replace facing.
Rivet
interference?
Replace defective
rivet.
Bounce plate
support bracket
loose or broken?
NO
NO
YES
YES
YES
YES
NO
Rebuild cushion
assembly.
Buna rubber worn
in corner?
