QubicaAMF XLi EDGE Series - Sweep Troubleshooting

Troubleshooting
400-088-120-02 Page 4.6-11 Rev. Date: 10/2016
Section 4.6
4.6.3 Sweep Troubleshooting
4.6.3.1 PROBLEM: Sweep runs up, down, and starts through to clean
off the deck a second time as the table spots pins. Table and
sweep stop because of interlock.
Figure 4.6-10
START
NO
Defective
encoder?
Replace encoder.
YES
Defective
chassis?
Replace chassis.
YES
