QubicaAMF XLi EDGE Series - Bin & Shuttle Assembly

Lubrication
400-088-120-02 Page 4.3-13 Rev. Date: 10/2016
Section 4.3
4.3.9 Bin & Shuttle Assembly
1. Shuttle pivot shaft sleeve bearings: 2 drops of oil (6 places) every 25,000 frames.
1
Figure 4.3-9
1
