QubicaAMF XLi EDGE Pinspotter
Section 4.4 Page 4.4-92 Rev. Date: 10/2016
4.4.4 Lane and Pinspotter Cleaning
4.4.4.1 Lane Cleaning
Turn off the power to the pinspotters and remove the power plug
before cleaning the lanes.
1. For daily lane cleaning, TURN OFF POWER TO THE PINSPOTTER either at the
mask, the chassis, or at the Manager’s Control Unit.
2. Knock the pins into the pit with a mop of broom.
3. After all the lanes have been cleaned, turn on the pinspotters and press the
cycle buttons or tenth frame switches to make the pinspotter ready for the first
ball.
4.4.4.2 Pinspotter Cleaning
Turn off the power to the pinspotters and remove the power plug
before cleaning the pinspotter.
The pinspotter must be kept clean to provide satisfactory service to the bowler. It is
important to maintain the cleaning schedule provided in this section.
Each Week
A. Wipe the following assemblies with a cloth dampened with a pin cleaner
such as “Topshot”.
Inside the bin and spotting cups
Pit carpet
Orientor pan and distributor funnels
B. Follow up by wiping down the items listed above with a vinyl dressing such
as Armor All
®
C. Vacuum between the kickback plates of adjacent machines as well as under
the light ball sensor and rudder arm assembly.
D. Vacuum under the carpet.
The EDGE Performance lift should be completely wiped down with diluted AP3
cleaner and dressed with a vinyl dressing every 25,000 frames.
